Multiple Ports Available

Multiple Ports Available

You can choose the appropriate number of ports as needed.

WiFi Optional, High-Speed Connection

WiFi Optional, High-Speed Connection

2.4G+5G dual-band WiFi, combined with 2.4G’s wall penetration capability and 5G’s fast speed, creates the ultimate Internet experience.

Network Management? So easy!

Network Management? So easy!

Both of EPON and GPON support a variety of management methods, remote maintenance, convenient and fast.

Innovative Products, Awarded 2+ Patents

Innovative Products, Awarded 2+ Patents

C-Data CATV series products have been granted two utility model patents：PCB board for assembling single fiber three-way optical devices and space shield structure of single fiber three-way optical devices.

Application Scenarios

  • catv onu for internet
  • catv onu for catv
  • catv onu for wifi

Technical Overview

  • catv onu
  • gpon catv
  • catv onu
  • gpon catv

FD714GW-R760 is an indoor fiber broadband access terminal. The device provides one GPON / EPON adaptive optical port and supports XPON mode. It can be used in connection with our company FD16/17 series GPON OLT or FD12 / 13 series EPON OLT. It can also interconnect with the mainstream manufacture (Huawei / ZTE / Fiberhome) GPON or EPON OLT to provide users with Internet, WIFI and CATV services based on GPON and EPON technology.


Datasheet Get Docs

Technical Specifications

Item
FD714GW-R760
Specifications
1*xPON + 4*GE RJ45 + 1*RF CATV + Wi-Fi
GPON/EPON Port
Single mode single fiber
GPONFSAN G.984.2 standard，Class B+
EPON1000BASE-PX20+ symmetric
GPON2.488Gbps/1.244Gbps downstream/upstream
EPON1.25Gbps downstream/upstream
WavelengthTransmit: 1310nm Receiver: 1490nm
Receiving sensitivityGPON：-28dBm EPON：-27dBm
Saturated powerGPON：-8dBm EPON：-3dBm
Transmitting powerGPON：0.5～5dBm EPON:0～4dBm
User Port(LAN)
RJ-45 connector

4*10/100/1000Mbps adaptive Ethernet port

Full/half duplex

Auto MDI/MDI-X
WIFI performance parameters
IEEE802.11b/g/n(2.4G)

IEEE802.11a/n/ac(5G)
Max rate300M(2.4G)
Max rate867Mbps(5G)
MAX TX power 2.4G17dBm
MAX TX power 5G17dBm
CATV（Input /Output port）Wavelength1550nm
RF frequency47MHz~1000MHz
RF impedance75Ω
Input optical power-18dBm～0dBm(with AGC)
RF output level78dBuV (@-12~-2dBm@85MHz) (with AGC)
RF output return loss>12dB(with AGC)
Indicators
PWR/PON/LOS/INT/LAN1-4/CATV/WIFI
Power
External 12V/1A power supply adapter

Power consumption:≤6.5W
Dimension and WeightItem Dimension234mm(L) x 157.5mm(W) x 32mm(H)
Item weightAbout 200g
Environmental SpecificationsOperating temperature0 to 40ºC
Storage temperature-40 to 85ºC
Operating humidity10% to 90%(Non-condensing)



Technical Specifications

Item

  • FD714GW-R760

Specifications

  • 1*xPON + 4*GE RJ45 + 1*RF CATV + Wi-Fi

GPON/EPON Port

  • Single mode single fiber

GPON

  • FSAN G.984.2 standard, Class B+

EPON

  • 1000BASE-PX20+ symmetric

GPON

  • 2.488Gbps/1.244Gbps downstream/upstream

EPON

  • 1.25Gbps downstream/upstream

Wavelength

  • Transmit: 1310nm

  • Receiver: 1490nm

Receiving sensitivity

  • GPON：-28dBm

  • EPON：-27dBm

Saturated power

  • GPON：-8dBm

  • EPON：-3dBm

Transmitting power

  • GPON：0.5～5dBm

  • EPON:0～4dBm

User Port(LAN)

  • RJ-45 connector

  • 4*10/100/1000Mbps adaptive Ethernet port

  • Full/half duplex

  • Auto MDI/MDI-X

WIFI performance parameters

  • IEEE802.11b/g/n(2.4G)

  • IEEE802.11a/n/ac(5G)

Max rate

  • 300M(2.4G)

Max rate

  • 867Mbps(5G)

MAX TX power 2.4G

  • 17dBm

MAX TX power 5G

  • 17dBm

CATV（Input /Output port）
Wavelength

  • 1550nm

RF frequency

  • 47MHz~1000MHz

RF impedance

  • 75Ω

Input optical power

  • -18dBm～0dBm(with AGC)

RF output level

  • 78dBuV (@-12~-2dBm@85MHz) (with AGC)

RF output return loss

  • >12dB(with AGC)

Indicators

  • PWR/PON/LOS/INT/LAN1-4/CATV/WIFI

Power

  • External 12V/1A power supply adapter

  • Power consumption:≤6.5W

Dimension and Weight
Item Dimension

  • 234mm(L) x 157.5mm(W) x 32mm(H)

Item weight

  • About 200g

Environmental Specifications
Operating temperature

  • 0 to 40ºC

Storage temperature

  • -40 to 85ºC

Operating humidity

  • 10% to 90%(Non-condensing)


Ordering Information

NO.Product ModelSpecificationsAccessories
1FD711G-F3601*xPON + 1*GE RJ45 + 1*RF CATVAC-DC Power Adapter: DC 12V/0.5A
2FD712XW-R4601*xPON + 2*GE RJ45 + 1*RF CATV + Wi-FiAC-DC Power Adapter: DC 12V/0.5A
3FD712GD-R4601*xPON + 2*GE RJ45 + 1*RF CATV + Dual-Band Wi-FiAC-DC Power Adapter: DC 12V/0.5A
4FD704G-X-R4101*xPON + 4*GE RJ45 + 1*RF CATVAC-DC Power Adapter: DC 12V/0.5A
5FD714GD-R8801*xPON + 4*GE RJ45 + 1*RF CATV + Dual-Band Wi-FiAC-DC Power Adapter: DC 12V/0.5A


Ordering Information

NO.

  • 1

  • 2

  • 3

  • 4

  • 5

Product Model

  • FD711G-F360

  • FD712XW-R460

  • FD712GD-R460

  • FD704G-X-R410

  • FD714GD-R880

Specifications

  • 1*xPON + 1*GE RJ45 + 1*RF CATV

  • 1*xPON + 2*GE RJ45 + 1*RF CATV + Wi-Fi

  • 1*xPON + 2*GE RJ45 + 1*RF CATV + Dual-Band Wi-Fi

  • 1*xPON + 4*GE RJ45 + 1*RF CATV

  • 1*xPON + 4*GE RJ45 + 1*RF CATV + Dual-Band Wi-Fi

Accessories

  • AC-DC Power Adapter: DC 12V/0.5A

  • AC-DC Power Adapter: DC 12V/0.5A

  • AC-DC Power Adapter: DC 12V/0.5A

  • AC-DC Power Adapter: DC 12V/0.5A

  • AC-DC Power Adapter: DC 12V/0.5A
