Designed to be installed in OSP locations: strand mount, wall, pole, cabinet or pedestal.
Multiple interfaces, support in-band & out-band management. High-power EYDFA is included in network management, convenient for maintenance. Remote management, solve problems with one click. Automatic alarm mechanism, troubleshooting timely.
| Model | FD1608Y |
| Management Rack | Field type slave equipment, Cast aluminum housing |
| Dimensions | 385mm(L)*306.95mm(W)*180mm(H) |
| Uplink Port | 2* 10/100/1000M auto-negotiation Ethernet ports 2 SFP interfaces 2 SFP+ interfaces |
| PON Port | Quantity: 8 Physical interface: SFP slot Interface type: GPON: ITU-TG.984.2 Class B+/Class C+ Max splitting ratio: GPON: 1:128 |
| Management Port | 1* 100/1000BASE-Tx out-band Ethernet port 1* CONSOLE local management port |
| Backplane Bandwidth | 78G |
| ITEM |
| |
| Specifications | 8*GPON + 2*GE + 2*GE SFP + 2*10GE SFP+ | |
| Management Rack | Type | Field type slave equipment,Cast aluminum housing |
| Uplink Port | 2* 10/100/1000M auto-negotiation Ethernet ports 2 SFP interfaces 2 SFP+ interfaces | |
| PON Port | Quantity | 8 |
| Physical interface | SFP slot | |
| Interface type | GPON: ITU-TG.984.2 Class B+/Class C+ | |
| Max splitting ratio | GPON: 1:128 | |
| Management Port | 1 100/1000BASE-Tx out-band Ethernet port 1 CONSOLE local management port | |
| PON Port attribute | Transmission distance | 20KM |
| Port rate | GPON: Downstream: 2.5Gbps Upstream: 1.25Gbps | |
| Wavelength | Forwarding: 1490nm Receiving: 1310nm | |
| Interface type | SC/UPC | |
| Fiber type | 9/125μm SMF (Single Mode Fiber) | |
| Light transmission power | Class B+ +1.5～+5dBm Class C+ +3～+7dBm | |
| Receiving sensitivity | Class B+ : -28dBm Class C+ : -30dBm | |
| Saturation power | Class B+ -8dBm Class C+ -12dBm | |
| Network management method | Support CLI、SNMP、TELNET、SSH、WEB | |
| Business capabilities | Support device log, device upgrade, device management, condition monitoring, configuration management, and user management. Layer 2 switching configuration management: Like port management, VLAN, RSTP, IGMP, ACL, QOS and so on. PON function configuration management: Like OLT authentication, DBA template, service template, line template and so on. Layer 3 function: support static routing, dhcp-relay and vlanif configuration | |
| Backplane Bandwidth | 78G | |
| Size | 385mm(L)*306.95mm(W)*180mm(H) | |
| Weight | 12.6KG | |
| Power supply | 220VAC | AC: 100V～240V，50/60Hz |
| Working environment | Working temperature | -40~65℃ |
| Storage temperature | -40～85℃ | |
| Relative humidity | 5～90% (Non-condensing) | |
| NO. | Product Model | Specifications | Accessories |
| 1 | FD1608Y | 8*GPON + 2*GE + 2*GE SFP + 2*10GE SFP+ | Optional 1*EYDFA module Pole-mounted/wall-mounted installation kits |
| 2 | FDC600Y | 2*8-port GPON OLT modules + 2*GE + 2*SFP + 2*SFP+ 1*EYDFA module | Pole-mounted/wall-mounted installation kits |
