WR535G
AX1800 Whole Home Mesh Wifi System

WR535G Mesh Router is is a gigabit dual-band mesh router. It adopts MTK mainstream chip solution. Its mesh protocol is based on the EasyMesh standard of the Wi-Fi Alliance.

It has the functions of self-organizing, self-repairing, and self-expanding. Mesh WIFI routers with multiple ethernet ports are perfectly matched and work together to eliminate signal dead spots, easily satisfying family scenes such as large flats, duplex, and villas, so that good signals can be achieved everywhere.

WR535G provides a maximum wireless access rate of 1800Mbps, 1 Gigabit WAN port, and 2 Gigabit LAN ports.

Technical Specifications

Item

WR535G

Specifications
1*GE RJ45 WAN + 2*GE RJ45 LAN + Wi-Fi5 + Mesh AX1800
Name
AX1800 Wireless Router
Model
WR535G
CPU
MTK CPU MT7621A
Memory /Storage
128MB/16MB
Wi-Fi Antennas
2×2.4GHz

2×5GHz

Internal 3dBi Gain
Protocol
IEEE 802.11a/b/g/n/ac
Wi-Fi Speed
2.4G Wi-Fi (Speed 600Mbps)

5G Wi-Fi (Speed 1200Mbps)
LEDPowerBlue Light Flashing: Mesh networking
2.4G Wi-Fi
Green Light Successfully connected Mesh
5G Wi-Fi
InterfaceWAN1 RJ45 port ,10/100/1000Mbps
LAN2 RJ45 port ,10/100/1000Mbps
ResetButton
Transmit Power2.4G23dBm
2.4G enhanced
5G21dBm
Power Supply
DC12V/1A Adapter
Power Consumption
<10W
Dimension
166x120x80mm
Operating Temperature
-10~50℃
Storage Temperature
-40~85℃
