WR525G
AX1800 Dual Band Gigabit Wi-Fi 6 Router

WR525G Wi-Fi 6 Routeris a new generation SOHO highperformance wifi6 router. It adopts an MTK chip, has 2.4g 2X2 and 5G 2X2 omnidirectional multi-band high-gain antennas.

The multi-oscillator high-gain omnidirectional antenna has a strong ability to pass through the wall and has a wider coverage, making the already strong signal more powerful, signal coverage is wider and data transmission is smoother. MU-MIMO multidevice transceiver technology from wifi6 that has low latency and stable connection of multiple devices at the same time to ensure a good experience of using multiple devices.

WR525G-AX1800 provides a maximum wireless access rate of 1800Mbps, 1 Gigabit WAN port, and 4 Gigabit LAN ports.

Technical Specifications

Item

WR525G

Specifications
1*GE RJ45 WAN + 4*GE RJ45 LAN + Wi-Fi6 AX1800
Name
AX1800 Wireless Router
Model
WR525G
CPU
MTK CPU MT7621DA/MT7621A
Memory /Storage
128MB/16MB
Wi-Fi Antennas
2×2.4GHz

2×5GHz

External 7dBi Gain
Protocol
IEEE 802.11a/b/g/n/ac/ax
Wi-Fi Speed
2.4G Wi-Fi (Speed 600Mbps)

5G Wi-Fi (Speed 1200Mbps)
LEDPowerGreen: Power on
Off: Power off
2.4G Wi-FiGreen:2.4G Wi-Fi up
Off:2.4G Wi-Fi down
5G Wi-FiGreen:5G Wi-Fi up
Off:5G Wi-Fi down
InterfaceWAN1 RJ45 port ,10/100/1000Mbps
LAN4 RJ45 port ,10/100/1000Mbps
ResetButton
Transmit Power2.4G23dBm
5G20dBm
Power Supply
DC12V/1A Adapter
Power Consumption
<12W
Dimension
234x148x31mm
Operating Temperature
-10~50℃
Storage Temperature
-40~85℃
